The AR44 axle was designed for both aesthetics and functionality. To improve upon the older AX10 axle, we designed the steering components with an 8 degree kingpin angle which results in a positive scrub radius. Making this change to the pivot point means less tire scrub for steering efficiency and less load on the steering servo.

• 8 degree kingpin angle
• Improved scrub radius over the AX10 axle

Universals_950

AR44 UNIVERSAL AXLE SET
Universal joint axles allow up to 45 degrees of steering and provide smoother action for a higher performing, efficient drivetrain.

• Up to 45 degrees of steering
• Smooth action for an efficient drivetrain
• Compact yet durable design
• Hardened steel construction

Ax90047_chassis_side_950
Ax90047_chassis_3qtr_950
Chassis_detail_950
Ax90047_35t_motor_470px
Ax10_transmission_470px
35T BRUSHED MOTOR, WATER RESISTANT
Providing an even balance of speed and crawling, the 35-turn brushed motor features a worry-free design with an integrated cooling fan allowing for extended periods of use. Easy operation: no tuning, no fuel, and no loud exhaust noise. Just plug 'n' go!


AX10™ TRANSMISSION
The ultra compact transmission allows for a wide range of gearing choices. The overall ratio can be adjusted using different pinion and spur gear choices allowing super high speed or competition level crawling speed.

• Three gear layout
• Metal motor plate
• 32P gearing
• Heavy duty slipper
• Sealed gear cover


Ax90047_front_links_470px
Ax90047_rear_links_470px

ALL STEEL SUSPENSION LINKS
Strong steel links for both suspension and steering. Large M4 rod ends for durability.

Cms_470px
Wb8_driveshaft_470px

CHASSIS MOUNTED SERVO (CMS)
Scale matters, but so does geometry! In pursuit of scale looks, we’ve moved the servo off the top of the axle and onto the chassis, just as a full size truck has its steering box located on the frame. But with this seemingly simple action comes a complexity of suspension hurdles to overcome - one of which is bump steer. The undesirable steering is caused by bumps interacting with improper length or angle of suspension and steering links. We made it our mission to design the front suspension in such a way that it eliminates or comes as close as possible to zero bump steer, to help give you the best driving experience possible.

• Scale looks with proper suspension geometry
• Anodized aluminum links included w/ M4 rod ends
• Adjustable servo mounting system allows for a wide range of servos to be used
• Properly designed suspension for nearly zero bump steer



WB8 HD WILDBOAR™ DRIVESHAFTS
WB8 HD Wildboar™ front and rear driveshafts feature an updated design with a larger diameter cross pin (2x11mm) along with an M4 Screw Shaft (2mm hex drive) for added strength. A center splined slider floats between each end and features added material which reduces flex and fatigue.

• 3-piece driveshaft with strengthened slider-floater tube
• Increased surface at the connection between the ball joints and output shaft tubes
• 2x11mm cross pin adds 25% more surface area providing more strength for the ball joint
• Captured cross pin design eliminates older set screw design for more durability/easy maintenance
• Adjustable length driveline parts included in box


Tire_470px
Wheel_470px

1.9 BFGOODRICH ALL-TERRAIN T/A® KO2 TIRES - S30
What lies between the dirt and metal are the tires - your connection to the trail below. When it comes to tough terrain, adventure seekers reach for BFGoodrich All-Terrain T/A® KO2 tires for their dependability on the roughest backroads.

• Officially licensed by BFGoodrich
• 4.65” x 1.65” / 1.9 (118mm x 42.5mm)
• S30 compound



1.9 METHOD MESH WHEELS
In an industry that's all about the latest and greatest, while taking advantage of styling trends, sometimes the 'less is more' approach is quite refreshing and the mesh wheel offers just that. Clean, simple and METHOD STRONG! These officially licensed METHOD Mesh Wheels are replicated in true form for durability and a clean line look.


Battery_tray_950

ADJUSTABLE BATTERY TRAY
The new adjustable battery tray is now relocated lower and further forward for better weight distribution and center of gravity (COG).

• Adjustable tray that prevents the battery from coming loose or shifting while driving
• Posts are included to fine tune the fit based on the battery you choose
• Easy access for quicker battery changes
• Can accommodate batteries up to 32x44x147mm (3S 5,000 mAh)


Scx10_2_frame_rails_950

STEEL C-CHANNEL FRAME RAIL CHASSIS
The realistic high strength c-channel chassis frame is made of durable steel with cross bracing for reinforcement and is held together with all hex hardware. Realistic looking frame and cross braces improve chassis rigidity (torsional stiffness). Realistic shock hoops with multiple shock mounting positions allows you to adjust your suspension for maximum performance. The simplified design makes maintenance and assembly quick and easy. The contoured skid plate significantly reduces hang-ups on terrain. Compared to the previous design, additional holes have been added to the rear portion of the frame rails for making wheelbase adjustments.

ADJUSTABLE WHEELBASE
This chassis is designed at 12.3” wheelbase length, but is easily adjusted to either a 11.4” or 12.0” wheelbase (optional link kits sold separately). Axial designed the chassis so that all the wheelbase adjustability happens out back without sacrificing front-end suspension geometry. Simple removal and installation of the suspension links and changing the drive shaft length allows an easier way to adjust the wheelbase.

• Wheelbase adjustment is easily done in the rear end without affecting the steering geometry and maintaining zero bump steer.
• Adjustable wheelbase (11.4”/ 12.0” / 12.3”) with optional links sold separately
• 4 link rear
• 12.3” wheelbase


Ax90047_bumpers_950

JCR OFFROAD VANGUARD BUMPERS AND XJ ROCK SLIDERS
Scale front and rear bumpers and rock sliders licensed by JCR Offroad.

• Rear mount has been extended and stiffer plastics chosen to help limit the typical sag seen in plastic bumpers
• Lenses included for light locations on bumpers
• Rear tow hitch included for added scale appearance
• Rock sliders specifically sized to fit the Axial Jeep® Cherokee body and the design allows for adjustable widths


Technical_partners_950
Ax90047_body_950

2000 JEEP® CHEROKEE BODY
Pre-painted body with molded scale detail parts (Grill with clear lenses, mirrors, door handles and liftgate trim panel).

Throughout the rich history surrounding the Jeep® brand, there have been several influential vehicles hailing from the seven-slot stable, one of which is the Jeep® Cherokee (XJ). Possibly considered as the dawn of the modern SUV, the XJ was first presented 1984 as one of the first small SUV’s introduced into the American market, which carried on until 2001. During its 17yr production run, the XJ was built on several continents for world wide exposure, offered in either a 2-door or 4-door configuration, available in several different trim levels along with either a 2wd or 4wd drivetrain. Under the hood featured three different engine options consisting of 2.5L I4 AMC (125hp @ 5400rpm and 150lb/ft of torque @ 3250rpm), 4.0L I6 OHC AMC (193hp@4600rpm and 231lb/ft of torque @ 3000rpm), and a Euro spec only turbo diesel I4 OHV (114hp@3900rpm and 221 lb/ft @ 2000rpm). In 97’, the XJ received a facelift that updated design queues focused on aerodynamics, body stiffness, styling as well as the spare tire being relocated from the rear bumper to inside the cab. The stiffer uni-body construction brought forth improvements in noise cancellation and vibrations while aerodynamics improved engine efficiency.

From an off-roading perspective, the XJ has proven to be a relatively inexpensive vehicle for purchase thus making it a value based build option, capable of suiting just about any sort of budget. Its bones are strong thanks to a Quadra-Link suspension system and primarily coming with Dana 35 axles since the beginning, but there was a Dana 44 option between 87’-91’. Don’t let its smaller size fool you, there’s room for four passengers and space for days, making it a great expedition rig for friends and family to tag along.


Receiver_box_electronics_wire_routing_950
RECEIVER BOX, WATERPROOF
Three different silicone seals are included, one for the antenna, one for the servo wires (includes three slots for three channels), and one that acts as a gasket for the receiver box cover. No more stress when running in mud, water, or snow!

• Waterproof receiver box located on the side plates allows easy access and low center of gravity


WIRE ROUTING
Wire routing has been thoroughly thought through to help keep your chassis layout looking clean. In addition to including wire clips/guides, there has been a channel created that runs the length of the chassis so you can run additional wires hidden inside the c-channel frame.

• Optional mounting points and wire routing for a chassis mounted servo winch and 2 speed shift servo


Yeti_dual_slipper_clutch_470
Ax90047_adjustable_shocks_470px

DUAL SLIPPER CLUTCH
Our dual slipper design uses a pad on each side of the spur gear for added surface area. This allows for more precise tuning and holding power. The spur gear features strong, 32 pitch gearing for high torque applications.

• Slipper design uses a pad on each side of the spur gear for added surface contact area
• More precise tuning and holding power
• Strong 32P gear pitch for high torque applications



ADJUSTABLE COILOVER SHOCKS
The threaded shock bodies hold a single coilover spring. They are oil filled and allow you to tune the dampening rate.

• All new shock towers with body mounts built in
• The body mounting system covers a larger range of positions and is a much more solid mount than previous
• No additional spacer needed when mounting shocks


Tactic_transmitter_470
Tactic_tr325_receiver_470
TACTIC TTX300 3-CHANNEL SLT RADIO
Sport-level racers and bashers will appreciate the Tactic TTX300's many popular features, along with its amazing adjustability. It features a programmable 3rd channel making for incredible versatility; it can operate functions such as two-speed shifting, winches and lights, making it ideal for a vast array of opportunities. Need more reasons? There's SLT (Secure Link Technology), which creates an unbreakable link between the receiver and your transmitter with push-button ease.

TACTIC 3-CHANNEL 2.4GHz RECEIVER
The Tactic TR325 2.4GHz receiver uses no crystals and features an internal antenna, so you'll experience worry free driving without frequency conflicts or antenna damage. This lightweight, compact, and bind button equipped receiver with LED indicator makes setup easy!

Ae-5_esc_470
Tactic_servo_470

AE-5 ESC, WATERPROOF
The Axial AE-5 ESC is 3S LiPo capable yet easily switched “in the field” between LiPO and NiMh battery types with a simple jumper – no more complex procedures.



• Male Star Plug lead - compatible with the most common polarized plug.
• Jumper 1 provides a simple plug and play choice between LiPo or NiMh.
• Jumper 2 switches Drag Brake settings.
• Waterproof design with Star Plug / laser etched heat sink.


METAL GEAR TACTIC SERVO, 151 oz-in, WATER RESISTANT
The included Tactic TSX45 metal gear servo is rated at 151 oz-in of torque for massive turning power and dual ball bearings provide smooth and precise movement for the metal gear train.



RECOMMENDED TERRAIN
Terrain_rocky_48x68
Terrain_mountainous_48x68
Terrain_offroad_48x68



REQUIRED ITEMS (not included)
Required_48x68_battery
Required_48x68_charger
Required_48x68_aa_batteries
Battery: 2S or 3S LiPo pack, or NiMH pack (batteries not included)



Bar_950x24
AX90047
SCX10 II™ 2000 Jeep® Cherokee 1/10th Scale Electric 4WD – RTR
816874016289



HIGH RESOLUTION IMAGES
Download_red_24x24



TUTORIALS, TIPS, AND TRICKS:



Axial AE-5 ESC Setup

Binding the Tactic TTX300 transmitter to the TR325 receiver

How to bind the Tactic TTX200 transmitter to the Tactic TR325 receiver. This is a great, lightweight backpacking option!






SKU AX90047
Barcode # 816874016289
Shipping Weight 4.0000kg
