Dualsky 30 Tuning Combo w/motor & ESC DSTC.4A.30E
More infoGet the best of both worlds with this tuning combo from Dualsky, consisting of an XC4018BA V2 ESC and ECO 2826C 850kv brushless outrunner.
Features
- ECO 2826C 850kv brushless motor
- XC4018BA ESC
- Suitable for .25 to .32 class, 2-stroke RC models
(DSTC.4A.30E)
- XM3548EA-5 brushless motor
- XC4018BA ESC
- Suitable for .25 to .32 class, 2-stroke RC models
- XM3548EA-5 Motor Specifications
- KV (RPM/V)
- 740
- Alias(Stator diameter, Magnet length)
- 2826
- Weight:
- 170g
- Diameter
- 34.5mm
- Length
- 46mm
- Diameter of Shaft
- 5mm
- Mounting holes pitch (mm)
- 19/25
- Slots,Poles
- 12,14
- Idle Current(Io) @10V
- 2.48A
- Resistance(Ri)
- 25mOhm
- Cruising power [8 mins]
- 369W
- Bursts current[15s]
- 45A
- Peak power [15s]
- 671W
- Recommended ESC
- XC4018BA
- Setup 1(No. of Cell, Prop.)
- 3S, 14x7
- Setup 2(No. of Cell, Prop.)
- 4S, 13x6.5
- Max. weight of sport models (kg)
- 1.8
- Max. weight of 3D models (kg)
- 1.2
- XC4018BA ESC Specification
- Dimensions (L x W x D)
- 52 x 28 x 14mm
- Weight
- 32g
- Number of Cells
- NiXX 6-18, 7.2-21.6V LiPo 2-6, 7.4-22.2V
- Resistance(Ri)(Ohm)
- 0.0031
- Max Cont. Current & Max Cont.Output
- 40A, 840W
- Max Burst Current & Max Burst Output
- 60A, 1224W
- BEC / Dissipative Power
- 5V/3A (Swiching)
- Programmable
- Throttle + ProgCARD V2
- Input Wires
- 120mm, 14AWG, DC3
- Output Wires
- 75mm, 16AWG, DB3
- Signal Wire
- 300MM JR
| SKU | DSTC.4A.30E |
| Barcode # | 6941047191099 |
| Brand | Dualsky |
