Overview
Hitec's HS-785HB Sailboat Sail Winch Servo
Features
  • Dual Ball Bearing Supported Output Shaft
  • Large Drum Wheel
  • Perfect replacement winch servo for the Pro Boat Ragazza
  • *** Warning: Do not use thread lockers on Karbonite geared servo as it will cause the output shaft to fail

The HS-785HB sail winch servo with it's large drum wheel has 3 1/2 revolutions of travel for hauling in even the largest of sails. With its dual ball bearing supported output shaft the HS-785HB will provide years of reliable service.

- (HTHS-785HB)
Size Category
Specialty
Type
Analog
Application
Sail winch
Torque
153 oz-in (11.0kg-cm) @ 4.8V; 183 oz-in (13.2kg-cm) @ 6V
Speed
1.68 sec/60 deg @ 4.8V; 1.38 sec/60 deg @ 6V, at no load
Length
2.32 in (59.0mm)
Width
1.14 in (29.0mm)
Height
1.97 in (50.0mm)
Weight
3.88 oz
Bushing Or Bearing
Bearing
Bearing
Dual
Motor Type
3 Pole
Connector Type
Universal
Gear Material
Karbonite
Current Draw Idle
8mA
Current Draw Stall
1500mA @ 4.8V; 1800mA @ 6V
Voltage
4.8V to 6.0V
Deadband
5µs
Brand
Hitec
SKU HRC33785S
Barcode # 669962330169
Brand Hitec RCD
Shipping Weight 1.0000kg
