The Axial SCX10 III Motobilt Valyrian Jeep JT Gladiator brings one of the most extreme off-road builds to life in detailed 1/10 scale. Featuring an officially licensed Jeep JT Gladiator body with a bobbed rear bed, Motobilt Waypoint trim details, KMC Grenade bead lock wheels, soft-compound Maxxis Trepador tyres and functional LED lighting, this 1/10 RC crawler combines authentic scale styling with proven Axial trail performance.

  • Officially licensed Jeep JT Gladiator body
  • Clipless body system
  • Motobilt Waypoint build trim with authentic scale details
  • Bobbed rear bed for improved departure clearance
  • Durable polycarbonate body, painted and assembled
  • Iconic Jeep 7-slot grille design
  • Detailed fender flares, door handles, hood vents and side mirrors
  • Official Jeep colour paint schemes
  • Inner fender wells for enhanced scale realism
  • Motobilt front and rear bumpers
  • Baja Designs LP6 bumper lights
  • Baja Designs S2 bed-rail lights
  • Scale 6.8 kg CO₂ tank mounted in the bed
  • Hi-Lift jack with dedicated bed mount
  • LED lighting on the bumpers, headlights, taillights and bed rack
  • Officially licensed KMC Grenade bead lock wheels
  • Maxxis Trepador tyres with soft compound
  • AR45 straight axles
  • Oil-filled shocks with aluminium threaded bodies
  • Front 3-link suspension
  • Rear 4-link suspension
  • 6 mm stainless steel suspension links
  • Stainless steel pivot balls on rod ends
  • Expandable steel C-channel chassis rails
  • Extended 353 mm wheelbase for increased stability
  • SCX10 III transmission with full ball bearings
  • All-metal internal transmission gears
  • Improved two-piece Panhard bar mount with double-shear protection
  • Skid plate with multiple link-mounting positions for adjustable suspension geometry
  • Factory-installed dig system with included servo and hardware
  • Dig function operated via the transmitter's third channel
  • Silicone elastomer battery straps
  • Compatible with standard and shorty battery packs

Description

Welcome to the world of extreme off-road driving. Axial brings that spirit to life with the SCX10 III Motobilt Waypoint Jeep JT Gladiator RC Rock Crawler. Partnering with Motobilt, this rig features licensed Jeep details, including the iconic seven-slot grille, detailed fender flares, moulded door handles, hood vents, and side mirrors. Official Jeep production colours and detailed inner fender wells provide outstanding scale realism. The bobbed bed carries a scale carbon dioxide tank and a heavy-duty jack, while bright LED lights illuminate night runs.

Underneath the beautiful polycarbonate body sits a rugged steel C-channel chassis designed to reduce frame flex and improve suspension articulation. The reliable AR45 straight axles feature a driver offset differential housing, supported by smooth oil-filled aluminium shocks and strong stainless steel suspension links. The transmission features all-metal internal gears and a unique Dig function, allowing you to lock the rear axle for tight turns on steep inclines. Powered by a dependable Axial Slick Rock brushed motor and a waterproof Spektrum electronic speed controller, this rig is ready for serious trail exploration.

Durable Metal Links & Pivot Balls

Durable Metal Links & Pivot Balls

The SCX10 III is built for long-lasting performance with durable metal links and pivot balls throughout the suspension system. These robust components ensure smooth articulation and precise handling, even under the stress of challenging off-road driving.

Rigid SCX10 III Steel Chassis

Rigid SCX10 III Steel Chassis

The SCX10 III range has a chassis that is built on a foundation of strength with sturdy steel C-channel frame rails. This rigid design minimises flex, resulting in more precise suspension movement and improved handling on challenging terrain.

AR45 Portal Axles

AR45 Portal Axles

The SCX10 III features AR45 portal axles that increase ground clearance at the differentials, allowing for greater off-road capability. This means you can tackle larger obstacles and navigate challenging terrain with ease.

Sealed Receiver Box

Sealed Receiver Box

This robust receiver box makes sure that the receiver is kept free from dirt and debris, ensuring it withstands the elements for reliable performance.

All Metal Gears

All Metal Gears

This SCX10™ III is built for extreme durability with an all-metal drivetrain. Every gear in the transmission, portals, and axles is crafted from metal, ensuring long-lasting performance and the ability to handle serious abuse.

Aluminium Adjustable Coil-Over Shocks

Aluminium Adjustable Coil-Over Shocks

The SCX10 III features oil-filled shocks with aluminium threaded bodies and a single coil over spring. These shocks are tunable, allowing you to fine-tune the damping rate and achieve optimal performance on various terrains.

Optimised Suspension Geometry

Optimised Suspension Geometry

The front suspension geometry reduces bump steer, while the rear 4-link minimises torque twist. The oil-filled shocks have aluminium threaded bodies with a single coil-over spring, tunable for achieving the best damping rate.

Reliable Power System

Reliable Power System

This Axial has the reliable Axial Slickrock 35T brushed motor and a Spektrum 40A waterproof brushed ESC. Designed for simplicity and reliability, you'll enjoy more trail time and minimal maintenance.

DIG functionality

DIG functionality

Use the Dig function to smoothly transition to front-wheel-drive by engaging the rear axle lock from your transmitter, enhancing turning ability and control. The Dig servo is provided and pre-installed so you are ready to rip up the trails as soon as you get it.

Adjustable Battery Mounting System

Adjustable Battery Mounting System

Swap power packs rapidly using flexible silicone elastomer straps instead of traditional hook-and-loop tape. This secure mounting setup accepts both standard and shorty battery sizes, allowing you to shift weight distribution perfectly for steep inclines and tricky descents.

Adjustable Skid Plate

Adjustable Skid Plate

Fine-tune your suspension geometry directly from the centre skid plate. Multiple upper link mounting positions allow you to adjust anti-squat characteristics, giving your rig maximum traction over loose rocks and steep ledges.

Upgraded Panhard Bar Mount

Upgraded Panhard Bar Mount

Navigate punishing rock crawls with absolute certainty using the newly redesigned Panhard bar mount. Constructed with a robust two-piece layout and double shear mounting points, this heavy-duty component ensures your steering remains locked-in even in the most extreme crawling environments.

Spektrum® SLT3® Radio

Spektrum® SLT3® Radio

Experience the thrill of responsive control with the Spektrum® SLT3® radio. Its superb SLT response rate ensures quick and precise commands, while the 50% and 75% throttle limit switch makes it perfect for beginners.  The comfortable foam steering wheel grip ensures long bashing sessions without fatigue.

Fully Licensed Tyres & KMC Wheels

Fully Licensed Tyres & KMC Wheels

This rig rides on officially licensed Maxxis Trepador tyres, which give it both a realistic look and high-performance crawling capabilities. These tyres are equipped with dual-stage, open-cell foam inserts, providing a soft outer layer for grip and a firm inner core for sidewall support. They are mounted on lightweight and durable one-piece KMC Grenade wh

Features

  • Durable Polycarbonate Body Features Iconic Jeep Grille Design

  • Motobilt Front And Rear Bumpers With LED Lights

  • Scale Bed Accessories Include Tank And Heavy Jack

  • Licensed KMC Grenade Wheels And Maxxis Trepador Tyres

  • AR45 Straight Axles With Offset Front Differential Housing

  • Oil-Filled Shocks With Aluminium Threaded Bodies And Springs

  • Expandable Steel C-Channel Chassis Rails Reduce Frame Flex

  • SCX10 III Transmission With All-Metal Internal Gears

  • Silicone Elastomer Battery Straps Accommodate Various Pack Sizes

  • Genuine Axial Product

Included Items

  • 1x Axial SCX10 III Motobilt Waypoint Jeep JT Gladiator RC Rock Crawler

  • 1x Spektrum SLT3 3-Channel Transmitter

  • 1x Spektrum SR515 Receiver

  • 1x Spektrum Firma 40A Brushed Waterproof ESC

  • 1x Axial Slick Rock 35-Turn Brushed Motor

  • 1x Spektrum S683 Servo With Steel Output Gear

  • 1x Spektrum SX108 Dig Micro Servo

  • 4x AA Batteries

  • 1x Product Manual

Required Items

  • 1x 11.1V (3S) LiPo Battery

  • 1x Compatible LiPo Battery Charger

  • 1x LiPo Safe Bag

Note

  • Please refer to the instruction manual for operation, safety, waterproof standards and maintenance instructions.

SKU AXI-2443T2
Brand AXIAL
SCALE 1:10
