More infoThis is the 8S version which, as of 10/12/2023, comes with a 90mm 12-Blade EDF 8S Power System with a 4075-1350Kv inrunner brushless motor and a thrust reversing 120A ESC.
The F-22 Raptor is the world’s first Fifth Generation fighter, and its technology and performance continue to set the standard against which all other fighter jets are judged. The Freewing F-22 is a flying RC replica of this innovative fighter jet. Boasting both the lowest stall speed and one of the highest top speeds among all of Freewing’s jets, this super scale F-22 is capable of executing maneuvers most other EDFs can only dream of –our design team considers it a Performer and a Trainer in one!
The Freewing F-22 is available in two PNP versions. The Standard version features a 90mm EDF with an all-new 9 blade single piece impeller, 3748-1750Kv outrunner brushless motor and 130A ESC. The Deluxe 8S version features a 90mm 12-blade impeller mounted to a powerful 4075-1350Kv inrunner brushless motor and a thrust reversing 120A ESC. The F-22’s maximum level airspeed exceeds 170KPH / 106MPH and 190KPH / 119MPH between the Standard and Deluxe versions, respectively.
Overall, the Freewing 90mm F-22 is a very approachable flyer and suitable for pilots moving up to their first 90mm jet from a smaller 70mm or 80mm jet. For pilots already familiar with the handling of a 90mm jet, the Freewing F-22 offers the potential to master an expanded set of realistic maneuvers.
Put stealth aside –stand out and be seen ruling the skies with your Raptor today!
 |
Super Scale Features a mixture of sharp panel lines, graduated paintwork, and realistic decals to create the most realistic PNP foam electric F-22 on the market. |
 |
Optimized Power System Efficient, balanced, powerful EDF power system generates speeds exceeding 100mph! |
 |
Versatile A large battery bay can easily fit either 6S or 8S battery (for appropriate 6S or 8S Power System). |
 |
Grass-Capable Strong aluminum suspension landing gear and sequenced nose gear doors. |
 |
Officially Licensed This Freewing F-22 is officially licensed by Lockheed Martin. |
 |
MultiShade™ livery 12 different colors and subtle shades in metallic, satin, and matte finishes of paint and decals combine to enhance the model’s visual representation of the real F-22’s stealth coating. |
 |
Multi-Material Using the right materials for the right job, the Freewing F-22 employs EPO foam, aluminum, carbon fiber, steel, nylon, plastic, and plywood. |
 |
User Friendly Servos are housed within plastic trays for easy removal and servicing, and the cockpit is lined with thin plastic to resist heat damage. |
 |
Easy-To-Transport Main wings disconnect conveniently with a flexible ribbon wire cable, which smartly reduces the load exerted on the actual electronic connections. A magnetic plastic nose cone also reduces the model’s length for easier transport. |
 |
Organized Integrated MFCB improves wire organization and supports DIY expansions such as LEDs. |
Features:
- NEW! 12 Blade EDF with 8S power system with 4075-1350Kv inrunner motor
- NEW! 120 Amp ESC with 8A UBEC and Thrust Reversing
- Model officially licensed by Lockheed Martin
- Exceptional low speed stability and high speed agility
- Realistic Scale Maneuver capability includes Cobra, Mongo Flip, J-Turn, Descending Spiral, Hover, etc
- Has the lowest stall speed and one of the highest top speeds among all of Freewing’s jets
- Large battery bay to easily fit either 6S or 8S battery (for appropriate 6S or 8S Power System)
- Materials include EPO foam, aluminum, carbon fiber, steel, nylon, plastic, and wood for maximum durability
- Features a mixture of sharp panel lines, graduated paintwork, and realistic decals for maximum realism
- MultiShade™ livery incorporating paint and decals with over 12 different colors and subtle shading in metallic, satin, and matte finishes
- Servos are housed within plastic trays for easy removal and servicing
- Cockpit is lined with thin plastic to resist heat damage
- Grass-capable suspension landing gear and sequenced nose gear doors with magnet assist
- Main wings disconnect conveniently with a flexible ribbon wire cable, which smartly reduces the load exerted on the actual electronic connections
- Magnetic nose cone encased in molded plastic with raised surface details can be removed easily to reduce the model’s length during transport to your flying field
- MFCB for wire organization and future expansion-potential with LEDs and optional accessories
- Widened gear stance and larger-than-scale grass-appropriate wheels greatly improve ground handling on short grass runways
- Ball Bearing-supported horizontal stabilators
- Screw-assembly for all flying surfaces
- Capable of Expert-level maneuvers as well as smooth, stable slow flight for less-experienced jet flyers
Includes:
- Freewing F-22 Raptor Ultra Performance 8S 90mm EDF Jet - PNP
- 12-Blade EDF power system (installed)
- 4075-1350Kv inrunner brushless motor (installed)
- 120A ESC with thrust reversing and EC5 connector (installed)
- Electronic retractable landing gear (installed)
- Servos, LED Lights (installed)
Requires:
- 6 Channel radio
- 6 Channel receiver
- TWO 4 Cell 14.8V 6000 mAh LiPo batteries with EC5 connector
- OR -
ONE 6 Cell 22.2V 5000 mAh LiPo battery with EC5 connector AND ONE 2 Cell 7.4V 5000 mAh LiPo with EC5 connector - EC5 2-to-1 series adapter -
- 4 Cell compatible battery charger
| Model Scale | 1 : 13 Scale |
| Wingspan | 1060mm / 41.73in |
| Length | 1500mm /59.05in |
| Empty Weight | 2960g / 104.41oz (w/o battery) |
| CG (Center of Gravity) | 150mm (5.9") from the leading edge of the wing at the root |
| Power System | 8S 4075-1350Kv Inrunner Brushless Motor |
| Electronic Speed Control | 120A thrust reversing, EC5 Connector |
| Propeller / EDF | 90mm 12-Blade EDF |
| Servos |
|
| Landing Gear | Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
| Required Battery | 6 Cell 22.2V 5000 mAh LiPo and 2 Cell 7.4V 5000 mAh LiPo batteries with EC5 connector in series - OR - Two 4 Cell 14.8V 5000 mAh LiPo batteries with EC5 connector |
| Required Radio | 6 Channel (required) |
| Ailerons | Yes |
| Elevator | Yes |
| Rudder | Yes |
| Flaps | Yes |
| Lights | Yes |
| Hinge Type | Nylon Reinforced |
| Material | EPO Foam |
| Skill Level | Intermediate/Advanced/Expert |
| Build Time | 3-4 Hours |
| Recommended Environment | Outdoor, 150+ foot paved runway or short manicured grass |
| SKU | FJ31331P |
| Brand | FREEWING |
