Features:

  • Large scale electric ducted fan RC jet sporting an accurate livery
  • 12 Blade factory balanced EDF with metal housing combined with 4068-1680kV Brushless Outrunner Motor produces realistic jet turbine sound (PNP only)
  • Composite fan blades combined with metal EDF housing ensure AMA compliance (the fan blades themselves are NOT metal, so there are no flying restrictions - PNP only)
  • 130 Amp Hobbywing ESC with 8A UBEC (PNP only)
  • Electric retracts with scale, shock-absorbing struts and main operation, CNC'd from 6061 aluminum and suitable for pavement or short grass
  • Electric wormgear-driven Slats
  • Servo operated Speed Brakes
  • Sequenced gear doors provide added realism and reduced drag
  • Integrated Junction Board to consolidate all wiring
  • Removeable wings and flight surfaces, including a magnetic nose cone, for easy transport and compact storage
  • Machine screws and brass threaded inserts are used to attach the wings for a secure fit and longevity
  • Bright LED navigation lights for enhanced realism and dawn/dusk maneuvers
  • Carbon fiber wing spars and reinforced body parts
  • Upgraded pushrod clevis and metal ball head connectors on elevators provide a robust connection between servo and control surface and eliminate "slop"
  • Nylon hinges on all control surfaces (superior to foam hinges)
  • All electronics and components are pre-installed for your convenience. Just plug in your receiver and battery, and fly! (PNP only)

Requires:

  • Minimum 7 Channel Radio
  • 7-9 Channel Receiver
  • 6 Cell 22.2V 5000 mAh
  • Lipo Battery Charger

Wingspan

1238mm / 48.7in

Length

1435mm / 56.5in

Flying Weight

4300g / 132.9oz

CG (Center of Gravity) See Instruction Manual

Power System

4068-1680kV Brushless Outrunner Motor (PNP only)

Electronic Speed Control

130A ESC, 8A UBEC, EC5 Connector (PNP only)

Propeller / EDF

90mm Metal Housing EDF with 12 Blade Fan (PNP only)

Servos

9g metal gear standard with 550mm lead: Left airbrake, nose gear door, rear cabin door, nose steering
9g metal gear reverse with 550mm lead: Right airbrake
9g metal gear standard with 100mm lead: Rear cabin right
9g metal gear reverse with 100mm lead: Rear cabin left
17g metal gear standard with 550mm lead: Left aileron, right aileron
17g metal gear standard with 300mm lead: Left flap
17g metal gear reverse with 300mm lead: Right flap
17g metal gear standard with 100mm lead: Left elevator, rudder
17g metal gear reverse with 100mm lead: Right elevator

Landing Gear CNC electric retracts with scale, shock-absorbing struts and main operation

Required Battery

6S 22.2V 5000mAh (Required)

Required Radio

Minimum 7 Channel (required)

Ailerons Yes

Elevator

Yes

Rudder Yes

Flaps

Yes

Lights

Yes

Hinge Type

Nylon hinges

Material EPO Foam
Skill Level Advanced
Build Time 2 Hours
