Giant scale servos, watch out! Our HS-1100WP Waterproof, heavy-duty digital giant brings out-of-this-world torque performance and strength to all your large scale vehicles, airplanes and robotic projects. Made with impressively durable steel gears, robust EMI-shielded cases and an IP-67* rated code for maximum underwater protection, this addition to our giant servo line have Hitec's unrivalled industrial digital circuitry and engineering. Your world just got BIGGER with the introduction of the HS-1100WP!

  • Nonprogrammable, Industrial Digital Circuitry
  • EMIshielded Cases
  • *International Protection Code 67 Rating
  • (6=Dust Tight; Complete Protection Against Contact 7) – Immersion up to 1 meter
  • Durable Steel Gears
  • 14.8V 4Cell LiPo Capability
  • 5Pole Carbon Brushed Motor
Performance Specifications
Operating Voltage Range (Volts DC)
11.1V ~ 14.8V
Speed (Second @ 60°)
0.26 ~ 0.19
Maximum Torque Range oz. / in.
1167 ~ 1528
Maximum Torque Range kg. / cm.
84 ~ 110
Current Draw at Idle
130 mA
No Load Operating Current Draw
1,300 mA
Stall Current Draw
6,500 mA
Dead Band Width
2 µs
Physical Specifications
Dimensions (Inches)
2.52 x 1.30 x 2.87
Dimensions (Metric)
64.0 x 33.0 x 73.0
Weight (Ounces)
12.8
Weight (Gram)
363
Circuit Type
Digital Amplifier with Mosfet Drive
Motor Type
5 Poles Caored Carbon Brushless
Gear Material
Metal
Bearing Type
Dual Ball Bearing
Output Shaft (type / Ømm)
Mega 15
Case Material
CNC Aluminum
Dust / Water Resistance
IP 67
Connector Gauge (AWG) / Strand Count
20 / 80
SKU HRC34110
Brand Hitec RCD
