The 954 SW servo HITEC D series offer the universal D the highest available on the market resolution of the servo travels. Finest response and programming possibilities are realized thanks to 32-bit MCU and 12-bit ADC technology. Wide-voltage servos can be connected directly to 2-cell-lithium-based batteries (LiFe/Li-IO/Li-Po) with a nominal voltage of 4.8 - 8.4 V.

The D954 SW servo is fully programmable and offers excellent durability thanks to its robust full steel gear and with ball bearings on output shaft, which is particularly well suited, if low backlash and high accuracy are important. The long lifetime and the uniquely designed transmission make it one of the most reliable and efficient servos on the market.

Programmable Functions

  • End Point Adjustments
  • Direction
  • Fail Safe
  • Dead Band
  • Speed (Slower)
  • Soft Start Rate
  • Overload Protection
  • Data Save / Load
  • Program Reset



  • High Resolution 32bit Digital Circuitry w/ 12bit ADC
  • 1M Cycle, Long Life Potentiometers
  • Wide Operating Voltage (4.8 ~ 7.4V)
  • IP65 Rated Cases
  • 25 Tooth Output Shaft
  • Customization and Modification Options Available
Operating Voltage Range (volts DC)
4.8V ~ 7.4V
No Load Speed (second @ 60°)
0.11 ~ 0.07
No Load Speed (RPM)
91 ~ 143
No Load Speed (deg. per sec.)
545° ~ 857°
Maximum Torque Range (oz. / in.)
112 ~ 182
Maximum Torque Range (kg. / cm.)
8.0 ~ 13.0
Maximum Torque Range (Ncm.)
78.5 ~ 127.5
Current Draw at Idle (mAh)
30
No Load Operating Current Draw (mAh)
500
Stall Current Draw (mAh)
5200
Dimensions (millimeters)
40.0 x 20.0 x 37.0
Weight (grams)
66
Motor Type
Coreless
Rated Motor Lifecycle
25,000 Cycles
Position Sensor
Mech Pot
Position Sensor Rated Lifecycle
1 Million
Gear Material
MK 1st Gear & 3 Steel Alloy Gears
Bearing Type
Dual Ball Bearing
Output Shaft (type / Ømm)
25 / 6
Case Material
Plastic / Aluminum
Dust / Water Resistance
Dust / Splash
SKU HRC36930
Brand Hitec RCD
