SPECIFICATION:
-   Wingspan: 1,450 mm  (57.09 in).
-   Length: 1,860 mm (73.23 in).
-   Flying weight: 4.6-4.9 kg (10.12-10.78 lbs).
-   Wing area: 43dm2.
-   Wing loading: 113g/dm2.
-   Wing type: Naca airfoils.
-   Covering type: Genuine ORACOVER®.
-   Gear type: Electric retract gear, size: (73.5 x 44 x 28)mm (not included).
     CNC Suspension Metal Struts (included).

Parts listing required (not included):
-   Radio: 08 channels.
-   Servo: 08 standard high torque servos, size: (29 x 13 x 30) mm.
-   EDF:  90mm 10 Blade Impeller.
-   Battery: 2 Packs * 5 Cells LIPO 37V.
-   Speed control: 120A.

Recommended EDF and Battery set up(not included):
-   EDFDS51 – AXI – HDS 90mm 10 Blade Impeller,  Minimum thrust 4 kg.
    HET 700 – 68 – 1200KV.
-   Lipo cell: 10 cells/5000mAh 55C.
-   ESC:120A Hobbywing Platinum

NOT INCLUDING ELECTRIC RETRACT GEAR.
ONLY INCLUDING CNC SUSPENSION METAL STRUTS.
ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER.





SKU BH-141A
Brand BLACK HORSE AIRCRAFT
Shipping Weight 10.0000kg
