605482087732
  • High Voltage (HV) capable (6.0-8.4v input range)
  • Outstanding torque and speed in a standard servo size (530 oz-in and .10 sec/60° @8.4v)
  • Durable and long lasting brushless motor
  • Low wear and tightly meshed all metal gear train
  • Dual bearing supported drive train helps maximize smooth operation
  • Aluminum servo case helps keep operating temperatures low
  • Soft start helps prevent component and airframe damage during un-intentional initializations
  • Over Current and Temperature protection
  • Helpful initialization start tone lets pilot know when the servo is ready
  • Integrated servo failsafe holds last known position if signal is lost
  • Frequency: 200Hz to 333Hz
Size Category
Standard
Type
Digital
Application
Airplane
Torque
378.37 oz-in (27.26 kg-cm) @ 6.0V; 467.06 oz-in (33.65 kg-cm) @ 7.4V; 530.22 oz-in (38.20 kg-cm) @ 8.4V
Speed
0.14 sec/60 deg @ 6.0V; 0.11 sec/60 deg @7.4V; 0.10 sec/60 deg @ 8.4V
Length
1.57 in (40mm)
Width
0.79 in (20mm)
Height
1.49 in (37.8mm)
Weight
2.81 oz (79.80 g)
Bushing Or Bearing
Bearing
Bearing
Dual
Motor Type
Brushless
Connector Type
Z-Connector
Gear Type
Metal
Gear Material
Metal
Voltage
6.0-8.4V
Deadband
<1ms
SKU SPMSA6300
Brand SPEKTRUM
