  • Removable wire harness with different lengths available
  • 7075 Aluminum hard anodized output shaft/main gear with steel internal gears
  • Aluminum case for good heat dissipation
  • Aluminum mounting tabs
  • NMB dual main bearings
  • 23T output shaft
  • Waterproof
  • 1-Year Limited Warranty
Size Category
Standard
Type
Digital
Application
1/8 Off-Road
Torque
238 oz-in (17.1kg-cm) @ 6V; 292 oz-in (21.0kg-cm) @ 7.4V; 331 oz-in (23.8kg-cm) @ 8.4V
Speed
0.09 sec/60 deg @ 6.0V; 0.08 sec/60 deg @ 7.4V; 0.07 sec/60 deg @ 8.4V, at no load
Length
1.61 in (41mm)
Width
0.82 in (20.9mm)
Height
1.38 in (35.1mm)
Weight
2.8 oz (79.4g)
Bushing Or Bearing
Bearing
Bearing
Dual
Motor Type
Coreless
Connector Type
Z-connector
Gear Type
Metal
Gear Material
Steel, Aluminum
Current Draw Idle
10.2mA @ 6.0V
Current Draw Stall
4900mA @ 6.0V
Voltage
6.0–8.4V
Deadband
2µs
SKU SPMSS6290
Brand SPEKTRUM
