Rating: 12VDC 50mA
Operating Temperature: -50 ~ 70 degrees C
Contact Resistance: 100mOhm Max.
Insulation Resistance: 100MOhm min at 100VDC
Withstand Voltage: 250VAC for 1 minute
Contact Arrangement: SPST
Momentary Action
LED Power Supply: 3.5-4V DC @ 25mA

Orientation Colour Cat #
Vertical Red SP-0612
Vertical Green SP-0613
Vertical Blue SP-0614
Horizontal Red SP-0615
Horizontal Green SP-0616
Horizontal Blue SP-0617
SKU AM-SP0614
Model # SP0614
Barcode # 9319236926567
