SPECIFICATION:

- Wingspan: 1,885mm (74.21in).

- Length:,1820mm(71.65in).

-Weight: 8.9 - 9.1kg (19.58 - 20 lbs).

- Wing area: 62.2dm2.

- Wing loading:143.1g/dm2.

- Wing type: NacaAirfoil.

- Gear type: Electric retract gear, size: (92.55 x 51 x 35.1)mm(not included).

CNC Suspension Metal Struts (included).



Parts listing required (not included):

- Radio:8 channels minimum.

- Servo: 8 Standard high torque servos, size: (33 x 17)mm.

-  Engine: EDF 120mm.

-  Battery: 10S - 12S LIPO  37V-44.4 V.

-  ESC: 160A.



Recommended EDF and Battery set up(not included):

-  Engine:Ducted Fan EDF JETFAN-120 eco Ejets+ HET 800-68-685.
 Battery: 12S LIPO –44.4V ≥6000Amh 40C.

-  Or Engine:Ducted Fan EDF Schubeler DS-86-AXI HDS 120mm + TP 5660-9D motor.

Battery: 10S LIPO -37V  ≥ 6000Amh 40C.

-  ESC: 160A Phoenix Castle.





OPTION  ELECTRIC RETRACT GEAR (NOT INCLUDING).
ONLY INCLUDING
CNC SUSPENSION METAL STRUTS.
ALL BALSA - PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED



SKU BH-175
Brand BLACK HORSE AIRCRAFT
